SRV2KL-IN
SRV2KL-IN
SKU:SRV2KL-IN
🔷 PRODUCT DESCRIPTION
The APC Easy UPS SRV2KL-IN is a high-performance online double-conversion UPS designed to deliver reliable and consistent power protection for critical IT equipment, small data centers, networking devices, and business applications. With its robust build and advanced features, this UPS ensures zero transfer time and uninterrupted operation during power disturbances. Built for efficiency and ease of use, the SRV2KL-IN offers a compact tower design, making it ideal for environments where space is limited but performance cannot be compromised. It provides pure sine wave output, ensuring compatibility with sensitive electronic devices.
🔷 KEY FEATURES
⚡ Online Double Conversion Technology
Provides continuous and clean power with zero transfer time, protecting against all types of power disturbances.
🔋 High Backup Capability
Supports extended runtime with external battery options, ensuring longer backup during outages.
📊 LCD Display Interface
User-friendly display for real-time monitoring of input/output voltage, load level, battery status, and system alerts.
🔌 Wide Input Voltage Range
Operates efficiently even in unstable power conditions, reducing dependency on battery mode.
🛡️ Advanced Protection
Safeguards equipment against overload, short circuit, battery deep discharge, and voltage fluctuations.
🌐 Generator Compatible
Works seamlessly with generator power, ensuring uninterrupted performance.
🔇 Low Noise Operation
Engineered for quiet environments like offices and server rooms.
🔄 Automatic Bypass
Ensures continuous power supply to connected loads even during internal faults.
🔷 Why Choose SRV2KL-IN?
✔ Reliable power protection for critical systems
✔ Cost-effective online UPS solution
✔ Easy installation and operation
✔ Trusted brand with global support
🔷 TECHNICAL SPECIFICATION
| Parameter | Specification |
|---|---|
| Model | SRV2KL-IN |
| Capacity | 2000 VA / 1600 Watts |
| UPS Topology | Online Double Conversion |
| Input Voltage Range | 110 – 300 V AC |
| Input Frequency | 40 – 70 Hz (Auto-sensing) |
| Output Voltage | 230 V AC ±1% |
| Output Frequency | 50/60 Hz ±0.1% |
| Waveform Type | Pure Sine Wave |
| Power Factor | 0.8 |
| Transfer Time | 0 ms (No transfer time) |
| Input Connection | Hardwired / IEC |
| Output Connections | IEC C13 (Typically 4–6 outlets) |
| Battery Type | Sealed Lead Acid (Maintenance-Free) |
| Battery Configuration | Internal Battery |
| Typical Backup Time | 10–20 minutes (depending on load) |
| Recharge Time | 4–6 hours to 90% capacity |
| Display Type | LCD Display Panel |
| Communication Ports | USB / RS-232 |
| SNMP Support | Optional (via network card) |
| Operating Temperature | 0°C to 40°C |
| Noise Level | < 50 dB |
| Efficiency | Up to 88–90% |
| Dimensions (H x W x D) | Approx. 336 x 190 x 425 mm |
| Weight | Approx. 17–20 kg |
| Protection Features | Overload, Short Circuit, Battery Deep Discharge, Overcharge |
| Application | Servers, Networking Equipment, Small Data Centers, IT Infrastructure |
