BX1100C-IN
BX1100C-IN
SKU:BX1100C-IN
🔹VALUE PERPOSTION
The APC BX1100C-IN 1100VA UPS is a reliable and efficient power backup solution designed to protect your essential electronic devices from power interruptions, voltage fluctuations, and surges. Built with advanced line-interactive technology, this UPS ensures consistent performance for home offices, desktops, networking devices, and small business applications. With a power capacity of 1100VA / 660 Watts, the APC BX1100C-IN provides sufficient backup time to safely shut down systems or continue short-duration operations during outages. It is an ideal choice for computers, routers, modems, and other sensitive electronics.
🔹 KEY FEATURES
-
Line-Interactive Technology
Provides stable power by regulating voltage fluctuations without switching to battery frequently. - Automatic Voltage Regulation (AVR)
Corrects low and high voltage conditions, ensuring consistent output and protecting equipment. -
Wide Input Voltage Range (145V – 290V)
Operates efficiently even in areas with unstable power supply. - Battery Backup & Surge Protection
Offers backup power during outages and protects devices from spikes and surges - Multiple Output Sockets
Comes with battery-backed and surge-protected outlets for connecting multiple devices. - Cold Start Capability
Allows the UPS to power on even without mains supply. -
Battery Saver Technology
Extends battery life by preventing unnecessary discharge. -
Audible Alarms & LED Indicators
Provides real-time alerts and easy monitoring of power conditions.
🔹 APPLICATION
The APC BX1100C-IN UPS is suitable for:
- Desktop computers and workstations
- Wi-Fi routers and modems
- POS systems
- Small office equipment
- Home electronics
🔹 Why Choose APC BX1100C-IN?
This UPS combines reliability, affordability, and essential protection features, making it a preferred choice for small offices and home users. Its compact design, efficient power management, and trusted APC build quality ensure uninterrupted productivity and data safety.
🔹 TECHNICAL SPECIFICATION
| Parameter | Specification |
|---|---|
| Model | BX1100C-IN |
| UPS Type | Line Interactive |
| Power Capacity | 1100 VA / 660 Watts |
| Topology | Line Interactive |
| Waveform Type | Stepped approximation to sine wave |
| Nominal Input Voltage | 230 V |
| Input Voltage Range | 145 – 290 V |
| Input Frequency | 45 – 65 Hz (Auto-sensing) |
| Input Connection | India 3-pin 6A |
| Output Voltage | 230 V |
| Output Frequency | 50 Hz (sync to mains) |
| Transfer Time | 10 ms typical (12 ms max) |
| Output Connections | 4 × Battery + Surge, 1 × Surge only |
| Efficiency (Full Load) | ~72% |
| Battery Type | Sealed Maintenance-Free Lead Acid |
| Battery Configuration | 2 × 12V (7.2 Ah typical) |
| Recharge Time | Approx. 6 hours |
| Battery Voltage | 24 V |
| Backup Time | Approx. 3 – 90 minutes (load dependent) |
| Surge Protection Rating | ~255 Joules |
| Control Panel | LED indicators (On-line, On-battery, Overload, Replace battery) |
| Audible Alarm | Yes (Battery mode, Low battery, Overload) |
| Operating Temperature | 0°C to 40°C |
| Humidity Range | 0 – 95% non-condensing |
| Dimensions (Approx.) | 259 × 132 × 282 mm |
| Weight (Approx.) | ~9 kg |
| Warranty | 1 Year |
| Application | Desktop PC, Routers, Home Electronics |
