SKU:SRV6KRIL-IN
🔹 PRODUCT OVERVIEW
The SRV6KRIL-IN is a 6 kVA / 6 kW rack-mounted UPS system engineered for small to medium-sized businesses that require dependable power backup and protection. It continuously converts incoming AC power to DC and then back to AC, isolating connected equipment from power disturbances such as voltage fluctuations, surges, spikes, and outages. This model features an intuitive LCD display that provides real-time information on load levels, battery status, input/output voltage, and system alerts. Its robust build and intelligent battery management system enhance battery life and ensure reliable performance over time.
🔹 KEY FEATURES
- Double Conversion Online Technology for complete power protection
- 6 kVA / 6 kW Capacity suitable for critical IT infrastructure
- Rackmount Design (Rack Installable) for space-saving deployment
- Wide Input Voltage Range for unstable power conditions
- Zero Transfer Time ensures uninterrupted operation
- LCD Display Panel for monitoring and control
- External Battery Support for extended backup time
- Advanced Battery Management for longer battery life
- Overload, Short Circuit & Surge Protection
- Compatible with Generator Power
🔹 APPLICATION
- Data Centers
- Server Rooms
- Networking Equipment
- Telecom Infrastructure
- IT & ITES Companies
- Industrial Control Systems
🔹 TECHNICAL SPECIFICATION
| Parameter | Specification |
|---|---|
| Model | SRV6KRIL-IN |
| Product Type | Online Double Conversion UPS |
| Capacity | 6 kVA / 6 kW |
| Form Factor | Rack Mount (Convertible Rack/Tower) |
| Input Voltage Range | 110 – 300 V AC (Full Load) |
| Input Frequency | 40 – 70 Hz (Auto Sensing) |
| Input Phase | Single Phase |
| Output Voltage | 220 / 230 / 240 V AC (Selectable) |
| Output Frequency | 50/60 Hz ±0.1 Hz |
| Output Waveform | Pure Sine Wave |
| Output Connections | Hardwired Output |
| Efficiency (AC Mode) | Up to 94% |
| Battery Type | External Battery Required |
| Battery Voltage | ±192 V DC |
| Typical Recharge Time | Depends on battery bank |
| Backup Time | Depends on external battery configuration |
| Transfer Time | 0 ms (Online UPS) |
| Display Type | LCD Display |
| Communication Ports | USB / RS232 / Smart Slot |
| Management Software | Supports PowerChute Software |
| Operating Temperature | 0°C to 40°C |
| Humidity | 0 – 95% Non-condensing |
| Noise Level | < 55 dB |
| Protection Features | Overload, Short Circuit, Battery Deep Discharge, Over-temperature |
| Compliance | CE, IEC Standards |
